TS-433eU | Compact 1U short-depth rackmount 2.5GbE NAS

Compact 1U short-depth rackmount 2.5GbE NAS – your affordable edge storage with NPU acceleration

The closer your data storage is, the faster you can access your data or applications! The TS-433eU with its sleek 1U short-depth rackmount design fits perfectly in tight spaces, making it ideal for flexible deployment. Deploy the TS-433eU closer to your operations to effortlessly create edge storage, and enjoy intelligent file management, secure backups, and seamless Docker container applications.

Space-saving

Flexible deployment for installation in small media cabinets or wall-mounted network racks.

The short rail kit Rail-S01 is recommended (optional purchase).
Powerful yet energy-efficient

The ARM Cortex-A55 quad-core processor with 4GB RAM uses up to 80% less power than similar x86-based NAS.
AI image recognition with NPU acceleration

The built-in NPU enhances AI-powered face recognition and accelerates subject identification in QNAP’s QuMagie smart album.
Dual 2.5GbE as standard

Attain faster data transfer and backup speeds by enabling Port Trunking or SMB Multichannel.
Easy storage expansion via USB

Connect a QNAP short-depth USB JBOD TR-004U to the TS-433eU to support up to 144 TB capacity (using 24 TB HDDs in RAID 5).
Backup and snapshot protection for peace of mind

Centralize all data backups to TS-433eU and regularly create snapshots to safeguard your data against ransomware threats.

The 1U short rackmount chassis saves space.

The TS-433The TS-433eU has a shorter chassis depth of only 11.51 inches (292.3mm), making it easy to install in various space-limited environments, including factories, small offices, audiovisual rooms, or surveillance rooms, offering flexibility and maximized space utilization.eU has a shorter chassis depth of only 11.51 inches (292.3mm), making it easy to install in various space-limited environments, including factories, small offices, audiovisual rooms, or surveillance rooms, offering flexibility and maximized space utilization.

Efficient multitasking with an energy-efficient ARM Cortex-A55 quad-core processor

Processor

ARM 64-bit Cortex-A55 4-core 2.0 GHz processor
Memory

Built-in 4GB RAM (non-expandable) for efficient multitasking and stable operation
Built-in NPU

Boosts AI image recognition performance and reduces CPU workload
AES Encryption

AES hardware-accelerated encryption enhances data read/write performance while ensuring data security

Transmission efficiency

1 x 2.5GbE SMB Sequential Throughput (1M)	Read 282 MB/s	Write 286 MB/s
1 x 2.5GbE SMB Encryption Sequential Throughput (1M)	Read 282 MB/s	Write 288 MB/s

2.5GbE as standard for enhanced performance

In modern business IT, a NAS with only 1GbE is a performance bottleneck. The TS-433eU comes with 2.5GbE connectivity as standard, enabling businesses to facilitate bandwidth-demanding applications, such as large file access, backup/restore, and container applications.

Built-in 2.5GbE

The TS-433eU comes with two 2.5GbE ports, outperforming similar competitor NAS that only provides 1GbE.

Enhance overall bandwidth

Obtain increased network speed and fault tolerance by configuring Port Trunking or SMB Multichannel.

NPU accelerates on-device AI performance. 6x faster face recognition

NPU (Neural-network Processing Unit), designed to speed up AI tasks, not only accelerates organization and classification in QuMagie smart album, but also reduces CPU workloads when fulfilling AI-driven requests. When uploading a large number of photos to the TS-433eU, you will enjoy high-speed AI performance of photo processing brought by NPU.

TS-433eU

Download Datasheet

CPU	ARM 4-core Cortex-A55 2.0GHz processor
CPU Architecture	64-bit ARM
Graphic Processors	Mali-G52
Floating Point Unit
Encryption Engine
Hardware-accelerated Transcoding
Neural Processing Unit (NPU)
System Memory	4 GB on board (non-expandable) Note: Reserves some RAM for use as shared graphics memory.
Maximum Memory	4 GB on board (non-expandable)
Flash Memory	4 GB (Dual boot OS protection)
Drive Bay	4x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility	3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives
Hot-swappable
2.5 Gigabit Ethernet Port (2.5G/1G/100M)	2 (2.5G/1G/100M)
Wake on LAN (WOL)
Jumbo Frame
USB 3.2 Gen 1 port	2
Form Factor	1U Short Depth Rackmount
LED Indicators	System Status, LAN, USB, HDD1~4
Buttons	Power, Reset
Dimensions (HxWxD)	43.3 × 430 × 292.3 mm
Weight (Net)	4.01 kg
Weight (Gross)	5.9 kg
Operating Temperature	0 - 40 °C (32°F - 104°F)
Storage Temperature	-20 - 70°C (-4°F - 158°F)
Relative Humidity	5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit	60W, 100-240VAC
Power Consumption: Disk Standby Mode	9.32
Power Consumption: Operating Mode, Typical	23.74 W Tested with drives fully populated.
Fan	3 x 40mm, 12VDC
System Warning	Buzzer
Kensington Security Slot
Standard Warranty	2
Max. Number of Concurrent Connections (CIFS) - with Max. Memory	200
