Name: QNAP TL-R1200PES-RP 12-Bay JBOD Enclosure
Brand: QNAP
Price: 5294 AED
Availability: InStock

Available for purchase! Occasional oversell due to in-store sales or high online demand; We will provide estimated lead time in such cases. Contact us for best wholesale price.

Real time 16 visitor right now

Sku: TL-R1200PES-RP

Barcode: 885022025589

Product type: RackNAS

Vendor: QNAP

QNAP TL-R1200PES-RP 12-Bay JBOD Enclosure

TL-R1200PES-RP PCIe Interface 12-bay JBOD, supporting SATA drives, for petabyte-scale expansion designed specifically for QNAP NAS

The TL-R1200PES-RP TL PCIe interface JBOD storage enclosure allows you to expand the storage capacity of a QuTS hero or QTS NAS by using SATA hard drives. Providing large data capacity and fast transfer speed, the TL-R1200PES-RP is the ideal solution for archiving/backing up virtualization applications, surveillance recordings, large data, and multimedia.

2.0 PB capacity

Expand up to 2.0 PB capacity for QuTS hero NAS, by connecting twelve expansion enclosures (up to 144 hard drives in total).
Economy

The TL-R1200PES-RP supports SATA hard drives, which are common, budget-friendly, and available with large capacities.
Up to 64 Gb/s

The TL-R1200PES-RP features PCIe Gen 3 x8, providing up to 64 Gb/s data transfer speed.

Note: Actual transfer speeds depend on the host NAS's PCIe slot and the storage units used.
Easy setup

Just connect your TL-R1200PES-RP to the host NAS to expand NAS capacity. RAID re-building on the host NAS is not required, and setup is finished within a few minutes.
Host-based power management

The TL-R1200PES-RP power on/off is linked with the host NAS.
Redundant power supply

Ensures service continuity with stable and reliable power supplies.

QNAP enterprise NAS with petabyte-class storage

Use QNAP enterprise and all-flash QuTS hero NAS paired with multiple TL-R1200PES-RP JBODs, to obtain both breakthrough performance and massive capacity. The TL-R1200PES-RP supports SATA hard drives, providing greater choice in selecting high-capacity drives. This configuration is ideal for enterprises, science research institutions, and media production companies that require high-capacity storage for backing up or storing virtual machines, containers, and what is produced/generated by their high-performance NAS.

Find your petabyte-class solution

	TL-R2400PES-RP	TL-R1600PES-RP	TL-R1200PES-RP
Drive bays per unit	24	16	12
Max. number of JBOD units connected	12	12	12
Max. number of total hard drives	288	192	144
Max. capacity	4.1 PB	2.9 PB	2.0 PB

Expand existing NAS storage pools

You can expand existing storage pools on the host NAS by simply adding a new RAID created on the TL-R1200PES-RP. RAID re-building or complicated settings are not required. All settings can be configured using Storage & Snapshots Manager on the host NAS. The TL-R1200PES-RP is a great solution for accommodating ever-increasing data or backup files.

Note: To achieve better performance, it is recommended to create storage volumes physically located within the same NAS or expansion enclosure, rather than creating storage volumes across the NAS or expansion enclosure.

Power on/off linked with host QNAP NAS

The TL-R1200PES-RP power status is linked with the host NAS, which helps to reduce hardware management tasks for IT staff.

Supported PCIe storage expansion cards

	QXP-3X8PES	QXP-3X4PES
Expansion ports	2	2
Interface	PCIe Gen 3 x8	PCIe Gen 3 x4
Supported cables	CAB-PCIE10M-8644-8X special cables	CAB-PCIE10M-8644-4X special cables

TL-R1200PES-RP

Download Datasheet

JBOD Connection Interface	PCIe
Drive Bay	12 x 3.5-inch The system is shipped without HDD. For the HDD compatibility list, please visit https://www.qnap.com/compatibility/
Drive Compatibility	3.5-inch bays: 3.5-inch SATA 6Gb/s, 3Gb/s hard disk drives 2.5-inch SATA 6Gb/s, 3Gb/s solid state drives You can only use one disk type (HDD or SSD) in a RAID group. Combining different types of disk in one RAID group is not supported.
Hot-swappable
Form Factor	2U Short Depth Rackmount
Host Interface	2 x SFF-8644 1x2 (in, out)
LED Indicators	Front panel: HDD 1-12, Power, Status, Link, Fan error Rear panel: SAS connector, Enclosure ID
Buttons	Power
Dimensions (HxWxD)	88.65 × 432 × 370.65 mm
Weight (Net)	9.22 kg
Weight (Gross)	14.02 kg
Operating Temperature	0 - 40 °C (32°F - 104°F)
Storage Temperature	-20 - 70°C (-4°F - 158°F)
Relative Humidity	5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit	300W (x2), 100 - 240V
Power Consumption: HDD Sleep Mode	43.4 W
Power Consumption: Operating Mode, Typical	78.2 W Tested with drives fully populated.
Fan	2 x 80mm, 12VDC
System Warning	Buzzer
QTS / QuTS hero
Supports JBOD cascading
Supports expanding NAS storage pools
Standard Warranty	5
Management	Managed via QNAP QTS / QuTS hero OS 1. Supports disk S.M.A.R.T. information 2. RAID expansion enclosure identifier 3. Locate RAID expansion enclosures 4. Locate hard disks on RAID expansion enclosure 5. Smart fan control by detecting system and hard drive temperature 6. Support Host-Based Power Management
