Name: signotec Delta LCD Signature Pad - ST-DERT-3-U100
Brand: signotec
Price: 2458 AED
Availability: InStock

Available for purchase! Occasional oversell due to in-store sales or high online demand; We will provide estimated lead time in such cases. Contact us for best wholesale price.

Real time 41 visitor right now

Sku: ST-DERT-3-U100

Product type: signotec Signature Pads

Vendor: signotec

signotec Delta LCD Signature Pad - ST-DERT-3-U100

SHORT DESCRIPTION

Flat input device for precise capturing of signatures with a high-resolution 10,1" (25.5 cm) full-color display for the brilliant display of A4 documents in original width and the signature in real-time as well as graphics and buttons. Thanks to the modern and ergonomic design, the pad is best suited for stationary use in the office or at your point of sale (POS). In addition, through the ER technology and the hardened glass surface, the lifetime has been increased to about 30 million signatures. The device has a USB connection cable with approx 2.7 meters length.

ETHERNET (RJ45)

The signotec Delta signature pad can optionally be delivered with an Ethernet connection (RJ45). This connection makes it possible to integrate the pad into the companys network and to control it via IP. For example for using the device from several workstations at the same time. But also the use over a further distance can be realized in this way.

The mode can be changed from USB to Ethernet or vice versa inside the service menu of the pad.

EQUIPMENT

Basically, everything you need is included. As an optional accessory for the signotec Delta, we offer a power adapter, which is needed if the power supply is insufficient, e.g. in operation via Ethernet.NEW: The signotec Delta is now available with Power over Ethernet (PoE), so that no additional power supply is required for a compatible IT infrastructures.

DISPLAY

Type

25.5 cm (10,1") Full-Colour LCD with LED-backlight

Colours

16.7 Million

Resolution

1.280 x 800 pixels

Scroll-Function

Yes, graphics up to 1.280 x 37.600 pixels

SENSOR

Type

ERT (Electromagnetic-Resonance-Technology)

Pen

batteryless special pen with changeable pen tip

Surface

particularly resistant, hardened special glass

Life expectancy

approx. 30 Million Signatures

Pressure Stages

2.048

Sample Rate

500 Hz, 4D Samples (x, y, z, t)

Active Signing Area

217 x 136 mm

Resolution

10.800 x 6.900 Pixel ≙ 1.264 x 1.292 dpi

SECURITY

Encryption

AES- and RSA-Encryption

Secure Mode

Real-time display of the signature without usable biometrics

PDF-Signature

RSA signature creation device inside the pad

Hash-Algorithms

SHA-256 und SHA-512

More information can be found below in the tab "Security features".

CONNECTION

Connection

USB (Y-Cable) (approx. 2.7 meters cable length)

Power Supply

USB (Y-Cable) or optional power supply

Network (TCP/IP)

Yes, optional with integrated Ethernet port (RJ45)

Terminal Server / Citrix

Yes, optional with Ethernet or signotec vCOM driver

Citrix Virtual Channel

Yes, optional with signotec Virtual Channel driver

OTHERS

Dimensions (W x D x H)

280 x 205 x 13-23 mm

Weight

approx. 650g

Status LED

2-colour status LED

Slideshow

Yes, up to 16 images as self-sufficient slideshow inside the pad

Customization

Change of housing color and logo print (on request)

Warranty

2 years
