Processor
Processor name - Intel® Xeon® Gold 5416S (16 core, 2.00 GHz, 30 MB L3, 150W)
Processor number - 1 processor included
Processor core available - 16 core
Processor speed - 2.00 GHz
Processor cache - 30 MB L3
Server Memory
Memory type - HPE DDR5 Smart Memory
Included memory - 32 GB (1x32 GB, 4800 MT/s)
Server Accelerator
Accelerators - Optional
Server Cooling
System fan features - 5x Standard Fans
Server Expansions
Expansion slots - 2-slots (x16 FH, x16 HH) as standard.
Upgradeable to 3rd slot in HH (or remove Slot 2 bracket to be FH at Slot 3) in a 2nd processor configuration. And maximum 2 OCP 3.0 PCIe5 slots.
Server Form Factor
Form factor - 1U Rack
Server Controllers
Network controller - Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE
Storage controller - Embedded SATA controller
Server Drives
Included drives - None ship standard, 8 SFF supported
Optical drive type - Optional - HPE 9.5mm SATA DVD-RW Optical Drive, HPE Mobile USB DVD-RW Drive.
Server Power
Power supply type - 1x HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit
Management Software
Infrastructure management - Included - HPE iLO Standard with
Intelligent Provisioning (embedded), HPE OneView Standard (requires download).
Security
Security - UEFI Secure Boot and Secure Start support.
Intel® Software Guard Extensions (SGX) support.
Immutable Silicon Root of Trust.
Optional Trusted Supply Chain, iLO Security modes, TPM,
Chassis Intrusion detection and Bezel Locking kits.
Warranty
Warranty - 3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, visit https://www.hpe.com/support
Weights and Dimensions
Weight - 32.33 kg (71.275 lb)
Dimensions - 24.1 x 60 x 99 cm (9.49 x 23.62 x 38.98 in)
