Processor
Processor nameIntel® Xeon® Gold 5416S (16 core, 2.00 GHz, 30 MB L3, 150W)
Processor number1 processor included
Processor core available16 core
Processor speed2.00 GHz
Processor cache30 MB L3
Server Memory
Memory typeHPE DDR5 Smart Memory
Included memory32 GB (1x32 GB, 4800 MT/s)
Persistent memory typeNot available
Persistent memory media capacityNot available
Server Accelerator
AcceleratorsOptional
Server Cooling
System fan features4x Standard Fans
Server Expansions
Expansion slotsUp to 8 PCIe Gen5, and 2 OCP 3.0, for detailed descriptions reference the QuickSpecs
Server Form Factor
Form factor2U Rack
Server Controllers
Network controllerBroadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE
Storage controllerHPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Server Drives
Included drivesNone ship standard, 8 SFF supported
Optical drive typeOptional DVD-ROM via Universal Media Bay External support only
Server Power
Power supply type1x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Management Software
Infrastructure managementHPE iLO Standard with intelligent provisioning (embedded), and HPE Compute Ops Management
Security
SecurityHPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit.
Warranty
Warranty3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://support.hpe.com/hpesc/public/docDisplay?docId=sd00004309en_us. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, visit https://www.hpe.com/support.
Weights and Dimensions
Weight41.32 kg (91.095 lb)
Dimensions60 x 99.8 x 27.3 cm (23.62 x 39.29 x 10.75 in)
