Processor
Processor name - Intel® Xeon® Silver 4516Y+ (24 core, 2.20 GHz, 45 MB L3, 185W)
Processor number- 1 processor included
Processor core available - 24 core
Processor speed- 2.20 GHz
Processor cache - 45 MB L3
Server Memory
Memory type - HPE DDR5 Smart Memory
Included memory - 64 GB (2x32 GB, 5600 MT/s)
Server Accelerator
Accelerators - Optional
Server Cooling
System fan features - 4x Standard Fans
Server Expansions
Expansion slots - Up to 8 PCIe Gen5, and 2 OCP 3.0, for detailed descriptions reference the QuickSpecs
Server Form Factor
Form factor - 2U Rack
Server Controllers
Network controller - Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE
Storage controller - HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Server Drives
Included drives - 2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
Optical drive type - Optional DVD-ROM via Universal Media Bay External support only
Server Power
Power supply type - 2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Management Software
Infrastructure management - HPE iLO Standard with intelligent provisioning (embedded), and HPE Compute Ops Management (optional subscription available)
Security
Security - HPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit.
Warranty
Warranty - 3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://support.hpe.com/hpesc/public/docDisplay?docId=sd00004309en_us. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, visit https://www.hpe.com/support.
Weights and Dimensions
Weight - 41.32 kg (91.095 lb)
Dimensions - 60 x 99.8 x 27.3 cm (23.62 x 39.29 x 10.75 in)
