Processor
Processor name - Intel® Xeon® Silver 4510 (12 core, 2.40 GHz, 30 MB L3, 150W)
Processor number - 1 processor included
Processor core available -12 core
Processor speed - 2.40 GHz
Processor cache - 30 MB L3
Server Memory
Memory type -
HPE DDR5 Smart Memory
Included memory -
64 GB (2x32 GB, 5600 MT/s)
Server Accelerator
Accelerators -
Optional
Server Cooling
System fan features -
5x Standard Fans
Server Expansions
Expansion slots -
2-slots (x16 FH, x16 HH) as standard.
Upgradeable to 3rd slot in HH (or remove Slot 2 bracket to be FH at Slot 3) in a 2nd processor configuration. And maximum 2 OCP 3.0 PCIe5 slots.
Server Form Factor
Form factor -
1U Rack
Server Controllers
Network controller -
Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
Storage controller -
HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Server Drives
Included drives -
2x HPE 960GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
Optical drive type -
Optional - HPE 9.5mm SATA DVD-RW Optical Drive, HPE Mobile USB DVD-RW Drive.
Server Power
Power supply type - 2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Management Software
Infrastructure management -
Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download).
Optional - HPE iLO Advanced, HPE OneView Advanced and HPE Compute Ops Management (optional subscription available)
Security
Security-
UEFI Secure Boot and Secure Start support.
Intel® Software Guard Extensions (SGX) support.
Immutable Silicon Root of Trust.
Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits.
Warranty
Warranty
3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://support.hpe.com/hpesc/public/docDisplay?docId=sd00004309en_us. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, visit https://www.hpe.com/support.
