Technical specifications
- Port
- 4 × 10/100/1000BASE-T Ethernet ports
- Antenna
- 4 × external 5 dBi omnidirectional antennas
- LED
- System status LED on the rear
- Dimensions
(H × W × D) - 180 × 195 × 57.3 mm
(7.09 × 7.68 × 2.26 in)
- Power consumption
- ≤ 12 W
- Cooling
- Passive cooling
- Certification
- CE WEEE RoHS
Wireless
- Wireless protocol
- 2.4GHz: 802.11n/g/b
5GHz: 802.11ax/ac/n/a
- Spatial streams
- 2.4GHz 2×2 MIMO
5GHz 2×2 MIMO
- Wireless bandwidth
- 2.4G HT20/HT40
5G HT20/HT40/HT80
- Wireless rate
- Simultaneous dual-band: 1501 Mbps, including 300Mbps on the 2.4GHz band and 1201 Mbps on the5GHz band.
- Wireless roaming
- IEEE 802.11k/v
- MU-MIMO
- Upstream and downstream MU-MIMO
Software
- Internet connection
- Routing mode: DHCP/PPPoE/static IP
Bridge mode: Wired repeating/wireless repeating
- Mesh
- Support
- IPv6
- Support
- Security
- WPA3, anti-piggybacking, firewall, DMZ
- Network management
- Guest Wi-Fi, access allowlist and denylist, parental control at multiple time ranges, IP-based traffic control, scheduled Wi-Fi on/off
- Special features
- QoS traffic shaping, broadband password retrieval, packet fast-forwarding engine, virtual server, DDNS(NoIP,DynDNS), VPN(PPTP Client,L2TP Client)
- Management method
- H3C Magic APP management (iOS, Android), Web management
- Fault diagnosis
- Link detection
Internet access diagnosis
Operating environment
- Operating temperature
- 0°C to 40°C (32°F to 104°F)
- Storage humidity
- 10% to 90% RH, noncondensing
Package
- Packing list
- Integrated machine
Power adapter
Networking cable
Installation quick start
