| Hardware Specifications |
| Applied Models | Supports creating volumes across different units | - FS series:FS1018
- 19 series:DS2419+II, DS2419+
- 18 series:DS3018xs
- 17 series:DS3617xs
- 15 series:DS3615xs, DS2415+, DS2015xs
- 13 series:DS2413+
- 12 series:DS3612xs
- 11 series:DS3611xs, DS2411+
|
| Notes | - To have better performance, we recommend creating storage volumes physically located within the same NAS or Expansion Unit, rather than creating volumes across your NAS and Expansion Unit.
- DSM version requirement: 6.2.4-25556 or later version.
|
| Storage | Drive Bays | 12 |
| Compatible Drive Type* (See all supported drives) | - 3.5" SATA HDD
- 2.5" SATA HDD
- 2.5" SATA SSD
|
| Hot Swappable Drive* | |
| RAID Management through Synology DSM | |
| Notes | Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list. The use of non-validated components may limit certain functionality and result in data loss and system instability. |
| External Ports | Expansion Port | 1 |
| Appearance | Size (Height x Width x Depth) | 270 mm x 300 mm x 340 mm |
| Weight | 9.02 kg |
| Power | Power Recovery | Synchronized with the Synology DiskStation |
| Power Supply Unit / Adapter | 550 W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 51.23 W (Access)
21.71 W (HDD Hibernation) |
| British Thermal Unit | 174.69 BTU/hr (Access)
74.03 BTU/hr (HDD Hibernation) |
| Notes | Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s). |
| Temperature | Operating Temperature | 5°C to 35°C (40°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Others | System Fan | 120 mm x 120 mm x 2 pcs |
| Easy Replacement System Fan | |
| Noise Level* | 27.2 dB(A) |
| Notes | Noise Level Testing Environment: Fully loaded with Seagate ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology expansion unit at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%. |
| Certification | |
| Warranty | 5 Years |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) |
| Environment & Packaging |
| Environment | RoHS Compliant |
| Packaging Content | - Main Unit X 1
- User's Guide X 1
- Accessory Pack X 1
- AC Power Cord X 1
- Expansion Cable: Infiniband X 1
|
| Optional Accessories | |
