| CPU | CPU Model | AMD Ryzen V1780B |
| CPU Quantity | 1 |
| CPU Architecture | 64-bit |
| CPU Frequency | 4-core 3.35 (base) / 3.6 (turbo) GHz |
| Hardware Encryption Engine (AES-NI) | |
| Memory | System Memory | 8 GB DDR4 ECC UDIMM |
| Memory Module Pre-installed | 8 GB (8 GB x 1) |
| Total Memory Slots | 2 |
| Maximum Memory Capacity | 32 GB (16 GB x 2) |
| Notes | - Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
- Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
- For more information about the recommended memory configurations, please check the Hardware Installation Guide of your Synology product.
|
| Storage | Drive Bays | 12 |
| Maximum Drive Bays with Expansion Unit | 24 (RX1223RP x 1) |
| Compatible Drive Type* (See all supported drives) | - 3.5" SATA HDD
- 2.5" SATA SSD
|
| Hot Swappable Drive* | |
| Notes | - It is strongly recommended that you only install drives listed on your device's compatibility list. Storage pool and volume creation processes may fail when using unverified drives. Synology is unable to provide technical support for devices using unsupported components.
- "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
|
| External Ports | RJ-45 1GbE LAN Port* | 2 (with Link Aggregation / Failover support) |
| RJ-45 10GbE LAN Port | 1 |
| USB 3.2 Gen 1 Port* | 2 |
| Expansion Port | 1 |
| Notes | - This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
- The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
|
| PCIe | PCIe Expansion | 1 x Gen3 x8 slot (x4 link) |
| File System | Internal Drives | |
| External Drives | - Btrfs
- EXT4
- EXT3
- FAT
- NTFS
- HFS+
- exFAT
|
| Appearance | Form Factor (RU) | 2U |
| Size (Height x Width x Depth) | RS2423+ :88 mm x 482 mm x 552 mmRS2423RP+ :88 mm x 482 mm x 578 mm |
| Weight | RS2423+ :11.5 kgRS2423RP+ :11.9 kg |
| Rack Installation Support* | 4-post 19" rack (Synology Rail Kit - RKS-02) |
| Notes | The rail kit is sold separately |
| Others | System Fan | 60 mm x 60 mm x 3 pcs |
| Fan Speed Mode | - Full-Speed Mode
- Cool Mode
- Quiet Mode
|
| Easy Replacement System Fan | |
| Power Recovery | |
| Noise Level* | RS2423+ :52.3 dB(A)RS2423RP+ :56.2 dB(A) |
| Scheduled Power On / Off | |
| Wake on LAN / WAN | |
| Power Supply Unit / Adapter | RS2423+ :500 WRS2423RP+ :350 W |
| Redundant Power Supply | RS2423+ :-RS2423RP+ : |
| AC Input Power Voltage | 100 V to 240 V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | RS2423+ :119.95 W (Access) 46.21 W (HDD Hibernation)
RS2423RP+ :114.86 W (Access) 42.33 W (HDD Hibernation) |
| British Thermal Unit | RS2423+ :409.56 BTU/hr (Access) 157.78 BTU/hr (HDD Hibernation)
RS2423RP+ :392.18 BTU/hr (Access) 144.53 BTU/hr (HDD Hibernation) |
| Notes | - For more information on how power consumption is measured, refer to this article.
- Noise Level Testing Environment: A Synology NAS loaded with Synology 480GB SAT5200-480G solid-state drive(s) in idle state. Each G.R.A.S. type 40AE microphone is placed at a 1-meter distance from the front and rear of a Synology NAS. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
|
| Temperature | Operating Temperature | 0°C to 35°C (32°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification | - FCC
- CE
- BSMI
- VCCI
- RCM
- UKCA
- EAC
- CCC
- KC
- UL
|
| Warranty | 3-year hardware warranty, extendable to 5 years with Extended Warranty Plus |
| Notes | - Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions.
- The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
|
| Environment | RoHS Compliant |
| Packaging Content | RS2423+ : - Main Unit X 1
- Accessory Pack X 1
- AC Power Cord X 1
- Quick Installation Guide X 1
RS2423RP+ : - Main Unit X 1
- Accessory Pack X 1
- AC Power Cord X 2
- Quick Installation Guide X 1
|
| Optional Accessories | |
