Variable options to boost system computing performance
Equipped with a PCIe 3.0 slot, RS1619xs+ supports installing a 10GbE/25GbE NIC for fast data transmission. Built-in M.2 2280 SSD cache slots further benefit IO-intensive tasks, such as virtualization or mail server deployment.
M.2 SSD support
Dual M.2 2280 slots supporting NVMe/SATA SSDs
10GbE/25GbE support
optional high-speed network capacity for bandwidth-intensive environments
Synology RS1619xs+ External HDD/SSD Specs
| Number of Bays | 4x 2.5"/3.5"
2x M.2 (2280) |
| Inputs/Outputs | 4x RJ45 Gigabit Ethernet
2x USB-A 3.0 / 3.1/3.2 Gen 1 |
| Compatible Drive Interface | SATA (Unspecified Version) |
| RAID | RAID 0/1/5/6/10/Basic |
Computing
| CPU | Quad-Core: 2.2 to 2.7 GHz |
| Processor | Intel Xeon D-1527 |
| Total Installed Memory | 8 GB ECC DDR4 |
| User-Replaceable Memory | 1x 8 GB |
| Total Memory Slots | 4x DIMM |
| Maximum Memory Capacity | 64 GB |
General
| Number of Bays | 4x 2.5"/3.5"
2x M.2 (2280) |
| Inputs/Outputs | 4x RJ45 Gigabit Ethernet
2x USB-A 3.0 / 3.1/3.2 Gen 1 |
| Compatible Drive Interface | SATA (Unspecified Version) |
| Media Card Slots | No |
| Form Factor | Rackmount (1 RU) |
| RAID | RAID 0/1/5/6/10/Basic |
| Hot-Swap Support | Yes |
| PCI Expansion | 1x PCIe 3.0 (x8 Electrical) |
| Wake on LAN | Yes |
| Link Aggregation and Failover Support | Yes |
Networking
| Supported Protocols | AFP
CIFS
CalDAV
FTP
HTTP
HTTPS
L2TP
NFS
SMB
SNMP
WebDAV
iSCSI |
| iSCSI LUN | 512 |
| iSCSI Target | 256 |
| Max Concurrent Connections | 10,000 |
| Max Folders | 512 |
| Max Sync Tasks | 32 |
| Max Groups | 512 |
| Max User Accounts | 16,000 |
| Max Volume Number | 1024 |
| Max Cameras Supported | 75 |
Software
| Installed Operating System | Synology DSM |
| Supported File Systems | Internal: BTRFS, EXT4
External: BTRFS, EXT3, EXT4, FAT, HFS+, NTFS, exFAT |
| OS Compatibility | Windows 7
Windows 10
macOS 10.11 or Later |
| Mobile App Compatible | No |
| Supported Browsers | Chrome, Firefox, Internet Explorer, Safari |
| Supported Languages | Brazilian Portuguese
Czech
Danish
Dutch
English
French
German
Hungarian
Italian
Japanese
Korean
Norwegian
Polish
Portuguese
Russian
Simplified Chinese
Spanish
Swedish
Thai
Traditional Chinese
Turkish |
Electrical
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Source | Internal Power Supply |
| Power Consumption | 68.68 W (Typical)
34.78 W (Standby) |
| PSU Wattage | 2 x 150 W (Supports Redundancy) |
Environmental
| Operating Temperature | 40 to 95°F / 4 to 35°C |
| Operating Humidity | 5 to 95% |
| Storage Temperature | -5 to 140°F / -20 to 60°C |
| Certifications | BSMI, CCC, CE, EAC, FCC, Kcc, RCM, VCCI |
Physical
| Status Monitoring | LED Indicator |
| Audible Alarm | No |
| Cooling | 2x 40 mm Fans |
| Noise Level | 39.3 dBA |
| Built-In Speakers | No |
| Dimensions | 20.42 x 18.9 x 1.73" / 518.6 x 480 x 44 mm |
| Weight | 18.1 lb / 8.2 kg |
Packaging Info
| Package Weight | 24 lb |
| Box Dimensions (LxWxH) | 24 x 23 x 8" |
