CPU | AMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor |
CPU Architecture | 64-bit x86 |
Floating Point Unit | |
Encryption Engine | (AES-NI) |
System Memory | 8 GB SODIMM DDR4 (1 x 8 GB) |
Maximum Memory | 64 GB (2 x 32 GB) |
Memory Slot | 2 x SODIMM DDR4 Support optional ECC memory For dual-DIMM configuration, you must use a pair of identical DDR4 modules. |
Flash Memory | 5GB (Dual boot OS protection) |
Drive Bay | 5 x 3.5-inch + 4 x 2.5-inch |
Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives
2.5-inch bays: 2.5-inch SATA solid state drives 2.5-inch U.2 NVMe PCIe Gen3 x4 solid state drives (2.5-inch Bay #1 & #2) * 2.5-inch bay #1 & #2 support either U.2 NVMe SSDs or SATA 6Gb/s SSDs. ** U.2 NVMe solid-state drives can only be installed in 2.5-inch bay numbers 1 and 2. Installing these drives in other bays will damage the drive connectors. |
Hot-swappable | |
SSD Cache Acceleration Support | |
2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M) |
5 Gigabit Ethernet Port (5G/2.5G/1G/100M) | Optional via the QNA-UC5G1T USB to 5GbE network adapter |
10 Gigabit Ethernet Port | 1 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
Wake on LAN (WOL) | |
Jumbo Frame | |
USB 3.2 Gen 2 (10Gbps) Port | 1 x Type-C USB 3.2 Gen 2 3 x Type-A USB 3.2 Gen 2 |
Form Factor | Tower |
LED Indicators | HDD 1-5, SSD 1-4, Power/Status, LAN, USB |
Buttons | Power, Reset, USB Copy |
Dimensions (HxWxD) | 176.5 × 224.6 × 224.1 mm Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model) |
Weight (Net) | 4.34 kg |
Weight (Gross) | 5.08 kg |
Operating Temperature | 0 - 40 °C (32°F - 104°F) |
Storage Temperature | -20 - 70°C (-4°F - 158°F) |
Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit | External, 120 W, AC 100 to 240 V |
Power Consumption: HDD Sleep Mode | 41.2 W |
Power Consumption: Operating Mode, Typical | 55.41 W Tested with drives fully populated. |
Fan | 1 x 140mm, 12VDC |
System Warning | Buzzer |
Kensington Security Slot | |
Standard Warranty | 3 |
Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 2000 |
