QNAP TBS-h574TX Thunderbolt 4 NASbook - TBS-h574TX-i3-12G

Name: QNAP TBS-h574TX Thunderbolt 4 NASbook - TBS-h574TX-i3-12G
Brand: QNAP
Price: 5159 AED
Availability: InStock

TBS-h574TX

Make your creativity bloom with the lightning-fast Thunderbolt™ 4 All-Flash NASbook

Designed for film sets, small studios, small-scale video production teams and SOHO users, the compact TBS-h574TX Thunderbolt™ 4 all-flash NASbook elevates video production for optimum productivity. It packs high-speed I/O and Intel® Core™ performance required by video production, allowing creators using Mac® or Windows® to enjoy the smoothest experience ever in real-time video editing, large file transfer, video transcoding, and backup. The TBS-h574TX, as the bridge between pre-production and post-production, takes video projects and team collaboration to the next level. The TBS-h574TX runs the ZFS-based QuTS hero operating system that ensures data integrity. You can also switch to QTS operating system based on your needs.

Ultra-fast RAW file editing

With an E1.S to M.2 SSD adapter attached in each slot, you can flexibly install five E1.S or M.2 PCIe NVMe SSDs for lightning-fast multimedia file editing.
Stay agile for ongoing projects

Hot-swappable M.2 SSD and automatic RAID disk replacement enhance system reliability, reduce the risk of data loss, and smoothen ongoing projects.
Thunderbolt™ 4 for faster direct connections

Two Thunderbolt™ 4 ports allow directly connecting Mac®/PC workstations to the TBS-h574TX, delivering up to 20Gbps for 4K video editing.
Hybrid-architecture CPU for multitasking

The 13th Gen Intel® Core™ processors with hybrid-architecture (P-core and E-core) delivers high performance and efficiency.
2.5GbE and 10GbE as standard

2.5GbE and 10GbE networks accelerate large file transfer and allow for more connected devices/workstations by attaching a network switch.
Faster USB transfer

Two USB 3.2 Gen 2 (10Gbps) ports enable fast file import/export from/to external storage devices.

TBS-h574TX-i3-12G

CPU	Intel® Core™ i3-1320PE 8C(4P+4E)/12T up to 4.50GHz
CPU Architecture	64-bit x86
Graphic Processors	Intel® UHD Graphics for 13th Gen Intel® Processors
Floating Point Unit
Encryption Engine
Hardware-accelerated Transcoding
System Memory	12 GB on board (non-expandable)
Maximum Memory	12 GB on board (non-expandable)
Flash Memory	5GB (Dual boot OS protection)
Drive Bay	5 x E1.S up to 15mm (5x PCIe Gen3 x2) Pre-install adapter to support M.2 2280 for each slots
Drive Compatibility	E1.S or M.2 2280 PCIe NVMe
Hot-swappable
M.2 Slot	5 x M.2 2280 PCIe Gen 3 slots (via pre-installed adapter) The system is shipped without SSD. For the SSD compatibility list, please visit https://www.qnap.com/compatibility/
SSD Cache Acceleration Support
2.5 Gigabit Ethernet Port (2.5G/1G/100M)	1
10 Gigabit Ethernet Port	1 x 10GBASE-T (10G/5G/2.5G/1G/100M)
Wake on LAN (WOL)
Jumbo Frame
Thunderbolt Port	2 (Thunderbolt™ 4) Supports only Thunderbolt connections for Windows & Mac hosts and USB storage devices. Third-party Thunderbolt external storage devices are not supported.
USB 2.0 port	1
USB 3.2 Gen 2 (10Gbps) Port	2
HDMI™ Output	1, HDMI™ 1.4b
Form Factor	Set-top design
LED Indicators	Status, USB copy, SSD 1-5
Buttons	Status, USB copy, Reset
Dimensions (HxWxD)	60 × 215 × 199 mm Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)
Weight (Net)	2.24 kg
Operating Temperature	0 - 40 °C (32°F - 104°F)
Storage Temperature	-20 - 70°C (-4°F - 158°F)
Relative Humidity	5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit	120W Adapter (19VDC output, 100-240VAC input)
Power Consumption: Operating Mode, Typical	46 W
Fan	System fan: 2 x 40mm CPU fan: 1 x 75mm
System Warning	Buzzer
Max. Number of Concurrent Connections (CIFS) - with Max. Memory	1500
